| 软管代号 | 公称内径 | 软管尺寸 | 软管内径 | 软管外径 | 比较大工作压力 | 比较小爆破压力 | 比较小弯曲半径 | 配用套筒 | |
|---|---|---|---|---|---|---|---|---|---|
| PART NO. | mm | DASH | Inch | mm | mm | MPa | MPa | mm | |
| R1312 | 19 | -12 | 3/4" | 19 | 32.1 | 34.5 | 137.9 | 241 | S00621-12 |
| R1316 | 25 | -16 | 1" | 25.4 | 38.7 | 34.5 | 137.9 | 305 | S00621-16 |
| R1320 | 32 | -20 | 1.1/4" | 31.8 | 49.8 | 34.5 | 137.9 | 419 | S00621-20 |
| R1324 | 38 | -24 | 1.1/2" | 38.1 | 57.3 | 34.5 | 137.9 | 508 | S00621-24 |
| R1332 | 51 | -32 | 2" | 50.8 | 71.8 | 34.5 | 137.9 | 635 | S00621-32 |
